HANSA Union nut for O-ring 3/4''-16UNF KMO 2603612050

Union nut brass for O-ring 3/4''-16UNF connector fits tube size 12mm / 1/2''

Dimension (LxWxH): 15x22x22 mm
Weight: 0,024 kg
Part-No.: 2603612050

Made in Germany



Download PDF

Material: brass CW614N/617N (acc DIN EN12164)
Operating pressure rang up to 140bar
Operating temperature: -100°C to +200°C
Approved refrigerants:  HFC / PFC / CFC / HC / R290 / R744
with the exception of NH3 containing refrigerants.
Approved oils: PAG / POE

2603612050
4251692913260

Data sheet

Material design
Brass
Connection type
O-Ring
Connection
3/4''-16UNF
